| Specification of LM358LVIDGKT | |
|---|---|
| Status | Active |
| Package | Bulk |
| Supplier | Texas Instruments |
| Amplifier Type | General Purpose |
| Number of Circuits | 2 |
| Output Type | Push-Pull |
| Slew Rate | 1.5V/s |
| Gain Bandwidth Product | 1 MHz |
| -3db Bandwidth | – |
| Current – Input Bias | 15 pA |
| Voltage – Input Offset | 1 mV |
| Current – Supply | 90A (x2 Channels) |
| Current – Output / Channel | 40 mA |
| Voltage – Supply Span (Min) | 2.7 V |
| Voltage – Supply Span (Max) | 5.5 V |
| Operating Temperature | -40C ~ 125C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118″, 3.00mm Width) |
| Supplier Device Package | 8-VSSOP |
Applications
The LM358LVIDGKT is versatile and can be utilized across various industries due to its robust performance and reliability.
- Medical Devices: Its precision makes it ideal for medical equipment that requires high accuracy in measurements.
- Automotive Electronics: Suitable for automotive systems requiring stable voltage regulation.
- Industrial Automation: Used in control systems where precise timing and signal processing are critical.
- Consumer Electronics: Ideal for devices like smart home appliances that need reliable power management.
- Scientific Instruments: Essential for laboratory equipment that demands consistent performance under varying conditions.
Operating Temperature: -40¡ãC to +125¡ãC
Key Advantages
1. High Precision Amplifier: Offers ¡À1% accuracy over the specified temperature range.
2. Dual Operational Amplifier: Provides two independent amplifiers in one package, saving space and reducing costs.
3. Low Power Consumption: Operates efficiently at low voltages, consuming only about 6mA per amplifier.
4. Wide Operating Voltage Range: Can operate from a wide input voltage range of 2.7V to 36V.
Frequently Asked Questions
Q1: What is the typical application of the LM358LVIDGKT?
A1: The LM358LVIDGKT is commonly used in applications requiring dual operational amplifiers such as audio circuits, instrumentation amplifiers, and filter networks.
Q2: Is the LM358LVIDGKT suitable for high-temperature environments?
A2: Yes, the LM358LVIDGKT operates effectively within a temperature range of -40¡ãC to +125¡ãC, making it suitable for high-temperature applications.
Q3: In which specific scenarios would you recommend using the LM358LVIDGKT?
A3: The LM358LVIDGKT is recommended for scenarios involving precise signal conditioning, such as in biomedical monitoring systems, industrial control loops, and scientific measurement instruments.
